🛡️ High-Impact Metal Cable Trunking: The Ultimate Surface-Mount Solution
Robust Protection Meets Aesthetic Precision for Modern Wiring Management
Say goodbye to messy cables and vulnerable wiring. Our Preformed Metal Cable Duct is not just a cover; it is a comprehensive protection system engineered for environments where safety and organization are non-negotiable. Unlike standard PVC trunking, this system utilizes a 0.5mm Galvanized Steel (SGCC) core, providing a rigid, crush-proof barrier that safeguards critical electrical circuits from physical impact and environmental wear.
Designed for versatility, it bridges the gap between industrial ruggedness and commercial elegance. The Thermosetting Polyester Powder Coating ensures a smooth, uniform finish that resists yellowing and scratching, making it ideal for visible installations in offices, data centers, and manufacturing plants alike.
💡 Why Choose This Metal Wire Duct?
Military-Grade Impact Resistance (IK07 Rated)
Forget flimsy plastic. This trunking is rigorously tested to absorb 5 Joules of impact energy (equivalent to a 1kg mass dropped from 0.5m). It prevents internal cable damage from accidental knocks or falling debris, ensuring long-term circuit integrity.
Advanced Corrosion & Abrasion Defense
The electrostatic spray process creates a coating thickness of over 70μm (average). This creates a formidable shield against oxidation, moisture, and rust. With a surface hardness of ≥ Pencil H, the duct withstands the friction of cable pulling and routine maintenance without showing unsightly scratches.
Fire-Safe & Thermally Stable
Safety is paramount. The thermosetting polyester finish is cured at 200°C, rendering the surface non-flammable and highly resistant to heat deformation. It meets strict fire safety protocols, making it a secure choice for high-load electrical setups.
Sleek "Invisible" Integration
Finished in a standard White (RAL 9016), the trunking blends seamlessly with walls and ceilings. It transforms chaotic wire bundles into a clean, architectural element, significantly upgrading the visual quality of any room.
📋 Technical Specifications: Precision Engineered
| Parameter | Specification Details |
|---|---|
| Product Type | Preformed Metal Cable Trunking / Wire Duct |
| Base Material | 0.5mm Galvanized Steel (SGCC) |
| Surface Finish | Thermosetting Polyester Powder Coating |
| Dimensions | 16mm (W) × 16mm (H) × 1400mm (L) |
| Coating Thickness | Minimum 45μm (Average >70μm) |
| Impact Rating | IK07 (Withstands 5J Impact) |
| Surface Hardness | ≥ H (Pencil Hardness Test) |
| Color Code | White (RAL 9016) / Customizable |
| Certification | EN10204-3.1 Material Certification |
🏗️ Versatile Applications
This cabling system is the preferred choice for diverse sectors requiring reliable wire management:
Commercial & Office Spaces: Perfect for surface mounting on drywall or concrete to hide network and power cables without drilling.
Industrial Automation: Protects control wiring in factories from dust, moisture, and mechanical impact.
Data Centers: Ensures organized, fire-retardant pathways for sensitive server cabling.
Residential Renovations: An excellent solution for adding outlets or data points to older homes without chasing walls.
✅ Quality Assurance & Compliance
We don't just manufacture; we certify. Every batch of our cable duct undergoes a 100% Final Quality Inspection. From dimensional accuracy to coating adhesion tests, we ensure full compliance with drawing No. 47139423 DT-MDA-1616-1400/C.
Backed by a strict Control Plan and MTC (Material Test Certificate) availability, our galvanized steel trunking guarantees that your project meets the highest international safety and quality standards.
