Outdoor Optical Cable

Your Leading Outdoor Optical Cable Supplier



Shenzhen You Yuan Communication Co., Ltd, located in Shenzhen China. We are passionate working on Telecommunication industry for 20 years, mainly offering passive fiber optic materials and major focus on Last Mile FTTX and FTTR Networks. Our outdoor optical cable includes GYTC8S fiber optic figure 8, ADSS outdoor fiber cable, GYTS outdoor fiber cable and GYTA53 outdoor fiber cable. These optical cables are mostly used in building complex systems and can be used in various environments such as direct burial, pipelines, overhead, and underwater.




  • Metal Duct End Fitting
    The Metal Duct End Fitting (DT-MDEF) is a durable, powder-coated cap designed to safely seal 16x16mm and 30x26mm metal trunking. It eliminates sharp edges, protects cables, and ensures a clean,...
    read more
  • Metal Duct Flatcorner 90°
    The Metal Duct Flatcorner 90° is a precision-engineered accessory for metal trunking systems, available in 16x16mm and 30x26mm. Made of durable powder-coated galvanized steel, it ensures a...
    read more
  • Cable Duct Includes Cover 1400mm 16x16
    Engineered for superior electrical organization, this Heavy Duty Metal Cable Trunking provides robust protection for wiring in industrial and commercial environments. Manufactured from...
    read more
  • gytc8s fiber optic figure 8
    The gytc8s fiber optic figure 8 is named after its distinctive cross-sectional shape, which resembles the number 8.
    This design incorporates the optical fiber unit and a messenger wire into...
    read more
  • ADSS Outdoor Fiber Cable
    YY Optic GYTC8S Fiber Optic Cable (Arial and FTTH) Armor Stranded Loose Tube Steel Wire Strength Waterproof Figure 8 Self Supporting Outdoor GYTC8S cable, single-mode/multimode fibers are...
    read more
  • GYTS Outdoor Fiber Cable
    A GYTS outdoor fiber cable is a type of optical fiber cable designed for outdoor use, particularly in harsh environmental conditions. GYTS stands for "Non-metallic Strength Member, Central Loose...
    read more
  • GYTA53 Outdoor Fiber Cable
    A GYTA53 outdoor fiber cable is a type of optical fiber cable designed for outdoor and underground installations in harsh environmental conditions. The "GYTA53" designation refers to the cable's...
    read more

Why Choose Us

Rich Experience

Our company owns a fiber optic cable manufacturing plant located in Shenzhen, China, and has over 30 years of extensive experience in the production of fiber optic cables.

Production Capacity

It has a plant area of 10,000 square meters and is equipped with advanced fiber optic cable manufacturing equipment and testing and testing equipment.

Product Application

Our products are widely used in power transmission and transformation, pipeline, underwater, mine, indoor and other scenarios of long-distance communication and inter-office communication.

Quality Guaranteed

Our strength of advanced Management, strict quality control and product test has created a world-class production specification and function while maintaining a competitive price.



Introduction to Outdoor Optical Cable





Outdoor optical cables are specifically designed to withstand the environmental challenges present in outdoor installations. Unlike indoor cables, which are suitable for controlled indoor environments, outdoor cables are engineered to provide reliable and high-speed data transmission in various outdoor conditions.



Classification of Outdoor Optical Cable

Figure 8 Fiber Optic Cable GYFTC8Y Self-support Aerial Outdoor Optical Cable


Gytc8s Fiber Optic Figure 8

The gytc8s fiber optic figure 8 is named after its distinctive cross-sectional shape, which resembles the number 8. This design incorporates the optical fiber unit and a messenger wire into a single structure, providing both support and enhanced tensile strength.



GYTS Outdoor Fiber Cable

GYTS optical cable is a communication cable with the same transmission speed as light. GYTS outdoor fiber cables are designed to be rugged and weather-resistant, making them suitable for installation in outdoor environments. They are typically designed to withstand exposure to UV radiation, extreme temperatures, moisture, and other outdoor conditions.

ADSS Outdoor Fiber Cable
GYTS Outdoor Fiber Cable


ADSS Outdoor Fiber Cable

After a PSP moisture barrier is applied around the cable core, this part of cable accompanied with the stranded wires as the supporting part are completed with a PE sheath to be a figure-8 structure. The main application of the Outdoor GYTC8S Fiber Cable is in outdoor telecommunications and data communication networks, especially for long-distance connections and installations that involve challenging environmental conditions.



GYTA53 Outdoor Fiber Cable

A GYTA53 outdoor fiber cable is a type of optical fiber cable designed for outdoor and underground installations in harsh environmental conditions. Whether it's the construction of urban communication networks, connecting remote regions, or interconnecting data centers, the GYTA53 cable can provide outstanding performance and reliability, ensuring seamless information transmission.

GYTA53 Outdoor Fiber Cable



Specifications of Outdoor Optical Cable


Products model

GYTC8S

Products material

Optical fiber

Steel wire / tape

PE Jacket

OD of Self-support reinforcement

1.5 / 2.0 / 3.0mm

OD of Strength Member

Steel wire or steel strand

1.4-5.2 ± 0.1mm

PBT Loose Tube

1.8 ± 0.1mm

Outer Jacket thickness

1.6 ± 0.2mm

OD

12.3*19.8 ± 0.3mm

Net weight

127-210 ± 5kg

Span

100m

Minimum bend radius (Dynamic / Static)

25D / 12.5D

Tensile strength (Short / Long)

3000N / 1000N

Crush resistance (Short / Long)

1000N / 300N



Functions of Outdoor Optical Cable
1
2
Figure 8 Fiber Optic Cable GYFTC8Y Self-support Aerial Outdoor Optical Cable
1

More strength: The armored layer is provided using steel or aluminum and that lends more strength to the cable or it protects it from contacts such as excess bending or crushing or even jarring. This feature makes use of outdoor optical cables in places where mechanical stress is common including factories or where congested conduits are used and so on.



Reduced rodent damage: When under the ground or in remote places, damage from rodents is common and cables almost always are the source of some of these gnawing. The external sheath helps to reduce such actions so that the cable is not easily bitten through.



More protection: Outdoor optical cables provide better protection against being cut or compromised, which is essential in applications that require secure transport and handling of data.



More protection from environmental impact: Apart from mechanical protection which is the core reason for the use of the outdoor optical cables, these cables also provide protection from environmental elements such as wetness, chemicals as well as other destructive substances. This is important in order to keep the performance in bad conditions.



Increased pulling force resistance: With the inclusion of the armored layer, the cable is capable of resisting more pulling force during the installation stage, for example, pulling it through long or intricate lengths and not harming the internal fiber optics.



Low maintenance cost: Owing to an increased protection from physical and environmental damages, outdoor optical cables incur fewer damages and their repairs and maintenance are not frequent thus yielding cost benefits over the periods of use.



Usage of Outdoor Optical Cable


Aerial Installations: The cables are often used for aerial installations, where they are strung between utility poles, transmission towers, or other support structures. They are ideal for connecting remote locations, such as cell towers, to central network facilities.



Duct Installations: These cables are also suitable for underground duct installations. They can be routed through buried ducts to provide high-capacity connections between data centers, central offices, or remote sites. The robust design of GYTC8S cables ensures they can withstand the rigors of duct deployment and protect the optical fibers from moisture and physical damage.



Long-Haul Telecommunications: The cables are well-suited for long-haul telecommunications networks, including backhaul connections for mobile networks. They provide high-bandwidth, low-latency connectivity over extended distances, making them essential for reliable data transmission over long network spans.



Broadband Networks: These fiber cables play a vital role in expanding broadband access in both urban and rural areas. They enable internet service providers to extend their network reach to underserved regions, delivering high-speed internet access to more people.



Industrial and Utility Networks: The cables are used in various industrial and utility applications. They can be deployed to connect monitoring and control systems in industrial environments, smart grids, and utility substations.



Campus Networks: In large campus environments, such as universities or corporate campuses, GYTC8S cables can be used to create high-capacity fiber optic links between different buildings and facilities. This enables seamless data connectivity across the campus.



Rural Connectivity: These cables are crucial for expanding telecommunications and data connectivity to rural and remote areas. They support initiatives aimed at bridging the digital divide by bringing high-speed internet access to areas with limited infrastructure.



Installation Requirements for Outdoor Optical Cable


1. Never directly pull on the fiber itself. Fiber optic cables have Kevlar aramid yarn or a fiberglass rod as their strength member.
2. Never exceed the maximum pulling load rating. On long runs, use proper lubricants and make sure they are compatible with the cable jacket.
3. Never exceed the cable bend radius. Fiber is stronger than steel when you pull it straight, but it breaks easily when bent too tightly.
4. Never twist the fiber cable. Putting a twist in the cable can stress the fibers too.
5. Make sure your fiber cable is long enough for the run. Fiber splicing make things complicated and expensive. Try to make it in one pull.
6. Indoor cables can be installed directly, but you might consider putting them inside innerduct. You can get the innerduct with pulling tape already installed.
7. Plan the Installation. You can eliminate 95% of the problems installers can encounter by simply creating this plan.
8. Pull, do not push cables. Pushing can result in violation of the bend radius.
9. Monitor the supply reel. Monitoring the supply reel during installation is necessary to prevent violation of minimum bend radius.
10. Communicate along the path of installation. When installing long runs, communicate and monitor along the path of the installation.

Figure 8 Fiber Optic Cable GYFTC8Y Self-support Aerial Outdoor Optical Cable



Our Service


24 hours online One to One service

Conduct product consultation,product promotion and marketing activities,and technical support for customer needs.

Cargo transport service

We can arrange sea, land, rail and air transport.

After-sales service

Installation and commissioning of specific products;Respond to consumer questions,answer consumer inquiries,and deal with consumer comments.





Certificate

productcate-1-1
productcate-1-1
productcate-231-326



Packaging & Delivery


Packing

We pack imports in barrels with pallets;

One barrel every 2km/3km/4km;

The size of the barrel can be customized according to your requirements.

Payment Terms

T/T 30% as deposit, 70% paid before shipment.

Delivery Time

10 to 20 days after prepayment. Depends on your order items and quantity.

Delivery Terms

EXW, FCA, FOB, CFR, CIF, DDP.





FAQ



Q: What are the benefits of outdoor optical cables?

A: Outdoor optical cables offer excellent attenuation performance over a wide range of temperatures, resist water ingress, have rugged constructions to resist ultra-violet light, and tolerate a wide range of mechanical forces, crush resistance, corrosion resistance, and tensile resistance. In addition, outdoor optical cables provide fast transmission speed and long distances, good confidentiality, anti-electromagnetic interference, good insulation, good chemical stability, long life, and low loss

Q: What should be paid attention to in the construction and design of outdoor optical cable?

A: Outdoor optical cables consist of several layers that ensure optimal performance and durability. The central core, made of glass or plastic, carries the light signals. Surrounding the core is the cladding, which reflects the light back into the core to maintain signal integrity. The buffer protects the fiber from moisture and physical damage.

Q: What are the environmental requirements for outdoor optical cable?

A: Outdoor optical cables are designed to withstand the harsh outdoor environment. They are engineered to resist moisture, extreme temperatures, and other environmental factors that can degrade signal quality.

Q: What are the main placement considerations when installing outdoor optical cable?

A: To minimize cable tensions, reel vault locations should be set near the sharpest bend locations. Pulling and reel locations should also be set at corner vaults where possible. Identify lightwave equipment that will be used and ensure that the equipment will function properly with the fiber cable being installed.

Q: How to get outdoor optical cable installed?

A: You'll agree on how to get the connection into the home with the engineer. The engineer will drill a hole from the outside of the property for the full fibre cable. The engineer will install a junction box on the outside wall and run a full fibre cable from either a nearby telephone pole or underground cables.
